Swing Door Mounted Presence Sensor
The 105395 is a door-mounted presence sensor designed to provide safety protection for any swing, bi-fold, revolving and low-energy automatic doors.
Features
- Detection method: Active Infrared with Position Sensitive Detection (PSD)
- Detection range: 0′-7’10” (0-2.4m)
- Beam angle adjustment: 5°, 10°, 15°, 20°, 25°
- Power supply: 12-24VAC or VDC ±10%
Benefits
- Presence sensor mounts on either side or both sides of a door panel, depending upon the application
- On swing doors, while the door is opening, the presence sensor will sense and protect a person in its path and either slow or stop the door
- When the door is closing, the presence sensor will sense a person in its path and reopen the door
- Combines the most reliable active infrared technology available with Position Sensitive Detection (PSD) technology found in auto-focus cameras to ensure the precise pedestrian detection within the path of a moving door panel
- Each sensor module’s detection zone can be adjusted independently
