Advantex 60/61/62/63 Series Templates

Advantex 60/61/62/63 Series Templates

Series & FunctionMounting PlateAluminum Door Template
60 Series Master Reinforcing SheetT1000
60 / F60BP10T2300
6002WP / 6002WPBP10Device: T2300
Trim: T2316
6002DNV / F6002DNVBP10Device: T2300
Trim: T1143
6003CBK / F6003CBKBP12Device: T2300
Trim: T1157
6003R / F6003RBP12Device: T2300
Trim: T2314
6003WP / F6003WPBP12Device: T2300
Trim: T2316
6008DNV / F6008DNVBP10Device: T2300
Trim: T1004
6009DNV / F6009DNVBP10Device: T2300
Trim: T1004
6014DNV / F6014DNVBP10Device: T2300
Trim: T1004
Series & FunctionMounting PlateAluminum Door Template
61 Series Master Reinforcing SheetT1000
61 / F610BP10T2301
6102WP / 6102WPBP10Device: T2301
Trim: T2316
6102DNV / F6102DNVBP10Device: T2301
Trim: T1143
6103CBK / F6103CBKBP12Device: T2301
Trim: T1157
6103R / F6103RBP12Device: T2301
Trim: T2314
6103WP / F6103WPBP12Device: T2301
Trim: T2316
6108DNV / F6108DNVBP10Device: T2301
Trim: T1004
6109DNV / F6109DNVBP10Device: T2301
Trim: T1004
6114DNV / F6114DNVBP10Device: T2301
Trim: T1004
Series & FunctionMounting PlateHollow Metal Door Template
62 Series Master Reinforcing SheetT1000
62BP10T2302
F62BP10T2304
6201CNVBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1118
6202DNVBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1118
6202WPBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T2316
6202DNVBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1142
6203CBKBP12Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1157
6203CNVBP12Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1119
6203RBP12Standard Device: T2302
Fire-Rated Device: T2304
Trim: T2314
6203WPBP12Standard Device: T2302
Fire-Rated Device: T2304
Trim: T2316
6208DNVBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1003
6209DNVBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1003
6214DNVBP10Standard Device: T2302
Fire-Rated Device: T2304
Trim: T1003
Series & FunctionMounting PlateHollow Metal Door Template
63 Series Master Reinforcing SheetT1000
63BP10T2303
F63BP10T2305
6301CNV / F6301CNVBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1118
6302DNV / F6302DNVBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1118
6302WP / F6302WPBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T2316
6302DNV / F6302DNVBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1142
6303CBK / F6303CBKBP12Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1157
6303CNV / F6303CNVBP12Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1119
6303R / F6303RBP12Standard Device: T2303
Fire-Rated Device: T2305
Trim: T2314
6303WP / F6303WPBP12Standard Device: T2303
Fire-Rated Device: T2305
Trim: T2316
6308DNV / F6308DNVBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1003
6309DNV / F6309DNVBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1003
6314DNV / F6314DNVBP10Standard Device: T2303
Fire-Rated Device: T2305
Trim: T1003
